If not, then something is screwed up on the board itself.
Boosted Board Error Codes 3 Flashing Lights Full Out Ofīoosting 81 Charging Created Join Top posts may 25th 2020 Top posts of may, 2020 Top posts 2020 help Reddit App Reddit coins Reddit premium Reddit gifts about careers press advertise blog Terms Content policy Privacy policy Mod policy Reddit Inc 2021. Boosted Board Error Codes 3 Flashing Lights Code What I. Cam Signal - Green = Tooth Detected, below crank to run RPM (400RPM), Blue = Gap Detected, below crank to run RPM (400RPM), Red = Cam Error Detected, Off - Synced Properly. Crank Signal - Green = Tooth Detected, below crank to run RPM (400RPM), Blue = Gap Detected, below crank to run RPM (400RPM), Red = Crank Error Detected, Off - Synced Properly. TPS Calibration - Green - Calibrated, Red = Calibration Error, Cyan = DBW Pedal Calibration Error, Purple = DBW TB Calibration Error. Wideband Status - Blue = Too Hot, Too Cold, Slow Warmup, or Uncalibrated, Green = OK!, Red = Sensor Failure, Yellow = Sensor Heating, Off = Sensor Disabled. Engine Running - Green = Running - Yellow = No RPM
8 Built-in multi-color diagnostic LED's allow you to quickly identify a variety of potential system issues, such as a failed TPS Autoset - faulty crank or cam sensors, or potential oxygen sensor issues!. Free EFI Tuning Software for complete control of your Terminator X power plant. Integrated Datalogging to the 3.5” Handheld SD Card. Advanced Tables – 4x 1D Tables, 1x 1D per Gear Table, 4x 2D Tables, 1x 2D per Gear Table. Nitrous Control – Single Channel of Wet or Dry, Progressive or Non-Progressive, Rich/Lean Safeties, and target Closed Loop AFR. Boost Control – Boost vs Time, Boost vs Gear, Boost vs RPM, Boost vs Speed, Boost Safeties. 4 Outputs – Ground, PWM -, for accessories such as fans, boost control, nitrous control, IAC Kit, and More. 4 Inputs – 12v, Ground, 5v, and Frequency, for things such as additional pressure sensors, or activation triggers for nitrous activation, or a trans brake (Fuel and Oil Pressure Inputs are pre-terminated). Built in 1bar MAP Sensor, vacuum hose adapters included (1/8th – ¼ and 3/16ths) - or for Boosted applications, you can disable the internal MAP sensor, and utilize an external MAP Sensor, the harness comes with the connector terminated, making the installation a snap. Allow you to identify any Critical engine issues at a glance On-Board Diagnostic LEDS for: ECU Power – Engine Run – Wideband Status – TPS Calibration – Crank Signal – Cam Signal. Genuine Bosch LSU 4.9 Wideband Control (Will not work with LSU 4.2 Oxygen Sensors). Transmission Control (Terminator X Max Only). Drive-by Wire Throttle Body Control (Terminator X Max Only). Plug and play Domestic V8 engine control.
